New Constellation Series
draco 10
The Perfect Compact PC Chassis
Never Give in to
the Heat Dissipation
Mount for 3 x 120 mm Fans in the Front
The Draco 10 is the first M-ATX case supporting 3 x 120 mm fans in the front. The cooling performance surpasses some of the standard ATX Cases.
With the massive irregular air intakes in the front, the Draco 10 M-ATX mini-tower compact case makes itself powerful and creates special visual effects by the piercing ARGB lighting bar.
Tempered Glass Side Panel
The Draco 10 is well-equipped with a 4mm edge-to-edge tempered glass side panel. It allows you to show your dream PC configurations.
Full-Sized GPU Compatibility
Despite the compact size, the Draco 10 can still fully support all the mainstream graphics cards.
Motherboard Support: M-ATX, ITX
2.5" SSD: 3
3.5" / 2.5" : 2/2
Graphics Card Support: Up to ≤ 360 mm
(Without Front Fan)
CPU Cooler Support: Up to 165 mm
PSU Support: Up to 194 mm (with HDD) Up to 350 mm (without HDD)
All About Airflow
Irregular air intakes in the front not only enhance the cooling but also give you visual beauty. There are also massive air intakes at the bottom and top to provide your PC gear the best thermal dissipation.
Make the Cooling Better
The Draco 10 has excellent fan and radiator support, pushing the cooling performance to the next level.
I/O Panel
Cable Management
Sufficient space makes your build neat and clean.
Easy to Clean
Dust filters at the front, top, and bottom. They are easy to be removed and cleaned.
The all-new Constellation series Draco 10 is a beautifully compact case, keeping a full-sized GPU compatibility. With its small but functional design, The Draco 10 provides superior cooling support. Front ARGB lighting and irregular air intakes build up visual aesthetics for your gaming setup.
Case Specification
Dimensions 444 x 220 x 410 mm (DWH)
Form Factor Mini Tower
Materials SPCC + Plastic
Mainboard Support M-ATX, ITX
Front Access & Controls Power, LED Control Button, USB3.0 x 2 , MIC/AUDIO(HD)
Side Panel Tempered Glass Side Panel
Expansion & Drive Bays
Expansion Slots 4
3.5" /2.5" 2/2
2.5" 3
Fan Support
Front 3 x 120 mm / 2 x 140 mm
Top 2 x 120 mm / 2 x 140 mm
Rear 120 mm
Included Fan(s) 1 x 120 mm fan in rear
Radiator Support
Front 120 / 140 / 240 / 280 mm
Top 120 / 140 / 240 / 280 mm (RAM length ≤134 mm)
Rear 120 mm
Max GPU Length ≤ 360 mm (Without Front Fan)
Max CPU Cooler Height ≤ 165 mm
Max PSU Length ≤ 194 mm (with HDD)
≤ 350 mm (without HDD)
Dust Filter Front / Top / Bottom
Net Weight 5.3 Kgs
Gross Weight 6.2 kgs
Warranty 2 years
UPC# 0-761345-80016-7
